In industrial production, the sealing system of a pump is of great significance to the equipment. It is related to the operating efficiency and service life of the pump, as well as the safety and stability of the entire production system. There are numerous pump sealing methods, each with its own principles, application scenarios, and characteristics. The following is a detailed introduction to help you select a suitable solution.
Mechanical seals are widely used and have excellent sealing performance. They rely on one or more pairs of end faces perpendicular to the axis of rotation. Under the action of fluid pressure and the elastic force (or magnetic force) of the compensation mechanism, these end faces fit closely and slide relative to each other to prevent fluid leakage.
This type of seal is suitable for working conditions with high pressure, high temperature, high speed, or strict leakage requirements. It plays a crucial role in industries such as chemical engineering, petroleum, and power generation. According to structural features, it can be divided into single - end - face mechanical seals, double - end - face mechanical seals, multi - spring mechanical seals, etc., to meet different working requirements.
The packing seal is a traditional sealing method. Soft packing materials such as asbestos, graphite, and PTFE are filled into the annular space between the pump shaft and the pump casing. Then, pressure is applied through the gland bolts to make the packing deform radially, achieving fluid sealing.
It has a simple structure and low cost, and is often used in low - pressure, normal - temperature situations with less strict leakage requirements, such as water pumps and agricultural irrigation pumps. However, the packing needs to be maintained and replaced regularly, and the leakage amount is relatively large.
Dynamic seals use the centrifugal force generated by the rotation of the pump impeller or the hydrodynamic pressure effect of the fluid for sealing, without the need for additional complex sealing components.
They are commonly used in small - sized centrifugal pumps and self - priming pumps, such as domestic circulating pumps. They can be divided into auxiliary impeller seals, spiral seals, etc., and have a good sealing effect in small - sized pump equipment.
Labyrinth seals achieve sealing by setting up tortuous channels between rotating and stationary components. When fluid leaks, the channels increase the resistance and reduce the leakage amount.
They are suitable for the shaft seals of high - speed rotating equipment such as steam turbines and compressors. They are often combined with other seals to enhance the sealing effect. As a non - contact seal, it has little wear, but the sealing effect is greatly affected by the gap between components.
Oil seals are annular sealing parts made of rubber or plastic. They prevent the leakage of lubricating oil and the entry of external impurities by closely contacting the surface of the shaft with their lips.
They are often used for sealing the lubrication systems of rotating shafts, such as in the bearing parts of motors and reducers. They have a simple structure and low cost, but the applicable pressure and temperature ranges are relatively narrow.
Magnetic fluid seals are advanced sealing technologies. They use the liquid O - ring formed by magnetic fluid under the action of a magnetic field for sealing, achieving non - contact sealing.
They are suitable for high - vacuum, high - speed, and dust - free environments, such as in semiconductor manufacturing equipment and aerospace instruments. They have excellent sealing performance, almost achieving zero leakage, but the cost is relatively high.
Floating ring seals use the throttling effect formed by the tiny gap between the floating ring and the shaft to prevent fluid leakage. Usually, they need to be used in conjunction with a sealing oil system.
They are often used in high - pressure centrifugal pumps and compressors, such as hydrogenation pumps in oil refineries. They can adapt to high - speed and high - pressure working conditions, but the structure is complex and requires an auxiliary system to ensure normal operation.
Welded seals permanently connect the sealing parts through welding to completely eliminate leakage.
They are suitable for one - time - use scenarios or occasions with extremely high leakage requirements, such as the cooling pumps of nuclear reactors and aerospace equipment. They have extremely high reliability, but are difficult to repair, and often require the entire sealing part to be replaced as a whole.
Considerations for Selecting Pump Sealing Methods
When choosing a pump sealing method, the following factors need to be considered comprehensively:
