Centrifugal pumps are widely used in industrial production and daily life for fluid transportation. Their normal operation is crucial for many systems. However, during long - term use, various problems inevitably occur. Therefore, the maintenance and repair of centrifugal pumps are quite important aspects.
Insufficient flow rate is one of the common faults of centrifugal pumps. The reasons may be that there is air in the pump or the suction pipe, resulting in cavitation, which affects the normal suction and discharge of the liquid. For example, when a newly installed or repaired centrifugal pump is started, if it is not fully vented, this situation is likely to occur. In addition, impeller wear is also an important factor. Long - term use makes the blades of the impeller thinner and damaged, reducing the ability to push the liquid and thus affecting the flow rate. It is also possible that the suction pipeline is blocked. Debris, scale, etc. block the pipeline, limiting the inflow of the liquid.
When the head of a centrifugal pump cannot meet the actual requirements, it may be due to the low rotational speed of the pump. This may stem from motor failures or problems with the transmission device, such as loose belts or damaged couplings, which cause the impeller to rotate at a speed lower than the design requirement, unable to impart sufficient energy to the liquid to lift it to the required height. In addition, increased mechanical friction inside the pump, such as too small a gap between the impeller and the pump casing, or worn bearings, will consume part of the energy, reducing the actual output head.
When abnormal vibration and noise occur during the operation of a centrifugal pump, it may be due to the misalignment of the pump shaft and the motor shaft. This will generate periodic unbalanced forces during the operation of the pump, causing vibration and noise. Unstable foundations can also lead to similar problems. When the foundation is not strong enough or the anchor bolts are loose, the pump will shake during operation, exacerbating the vibration. In addition, there may be cavitation in the pump. The liquid vaporizes in the low - pressure area to form bubbles, which then burst in the high - pressure area, generating high - frequency impacts and causing vibration and noise.
For the situation of air in the pump, it is necessary to open the exhaust valve for full venting to ensure that the pump is filled with liquid. For impeller wear, it is necessary to repair or replace it according to the degree of wear. Slight wear can be repaired by methods such as surfacing welding and spraying wear - resistant materials; if the wear is severe, a new impeller needs to be replaced. If the suction pipeline is blocked, it should be disassembled and cleaned to remove debris and scale. If necessary, the pipeline can be chemically cleaned or replaced.
When the low rotational speed of the pump is caused by a motor failure, it is necessary to overhaul the motor, check whether the windings are short - circuited or open - circuited, and repair or replace the damaged components. If it is a problem with the transmission device, adjust the belt tension or replace the damaged coupling. For the situation of increased mechanical friction inside the pump, check and adjust the gap between the impeller and the pump casing, and replace the worn bearings to ensure the normal operation of the pump.
If the pump shaft and the motor shaft are misaligned, professional tools are needed for precise alignment to adjust the coaxiality of the two. For unstable foundations, strengthen the foundation, tighten the anchor bolts, and if necessary, perform secondary grouting on the foundation. When cavitation occurs, measures such as reducing the installation height of the pump, increasing the diameter of the suction pipe, and lowering the liquid temperature can be taken to reduce the occurrence of cavitation.
In addition to maintenance after failures, preventive maintenance of centrifugal pumps is equally crucial. Regularly check the operating parameters of the pump, such as flow rate, head, current, vibration, etc., and take timely measures to detect potential problems. Lubricate, clean, and replace vulnerable parts such as seals and bearings at specified intervals, which can effectively extend the service life of the pump, reduce the probability of failures, and ensure the continuous, stable, and efficient operation of the centrifugal pump.
Centrifugal pump maintenance is a systematic and professional task. Only by understanding common faults and their causes, mastering correct maintenance methods, and emphasizing preventive maintenance can we ensure that centrifugal pumps are always in good operating condition and provide reliable fluid transportation support for industrial production and social life.
In conclusion, centrifugal pumps are key equipment for fluid transportation in industrial production and daily life, and their stable operation is of great significance. Maintenance work is not only a means to restore equipment functions after failures but also an important link to ensure the continuity of the entire production process and reduce operating costs. Deeply understanding the common faults and maintenance methods of centrifugal pumps and actively carrying out preventive maintenance work can effectively improve the operating efficiency and reliability of centrifugal pumps and lay a solid foundation for the stable development of various industries.
